High Performance Motoman Welding Robot - YASKAWA laser welding robot MOTOMAN-AR900 – Jiesheng Detail:
Compared with the previous models, the MOTOMAN-AR series of Yaskawa arc welding robots has improved freedom of movement, compactness and reduced the size of the robot. Robots can be placed in high density, which saves space for customers on production equipment.
The small workpiece laser welding robot MOTOMAN-AR900, 6-axis vertical multi-joint type, maximum payload 7Kg, maximum horizontal elongation 927mm, suitable for YRC1000 control cabinet, uses include arc welding, laser processing, and handling. It has high stability and is suitable for many This kind of working environment, cost-effective, is the first choice of many companies MOTOMAN Yaskawa robot.
The laser welding robot MOTOMAN-AR900 can be equipped with a variety of servo welding guns and sensors. Through high-speed action, it can reduce the beat. It adopts a design that reduces the interference between the arm and the peripheral equipment, and is suitable for small parts welding.
| Controlled Axes | Payload | Max Working Range | Repeatability |
| 6 | 7Kg | 927mm | ±0.01mm |
| Weight | Power Supply | S Axis | L Axis |
| 34Kg | 1.0kVA | 375 °/sec | 315 °/sec |
| U Axis | R Axis | B Axis | T Axis |
| 410 °/sec | 550 °/sec | 550 °/sec | 1000 °/sec |
The innovation of this new laser welding robot in structure, performance and function improves the freedom of movement and the compactness of the body. It has realized the simplification of the installation process and improved production efficiency. Moreover, the company is an authorized first-class after-sales service provider of Yaskawa, and equipment maintenance is guaranteed.
